Prepare samples by adding lysis buffer and bead solution as appropriate to sample and homogenize it into the 96-well plate.
Using the touchscreen interface, program the incubation temperature, duration, and agitation speed. The extractor will automatically with extraction, including magnetic bead capture, washing, and elution.
Once extraction is complete, the system will dispense purified nucleic acid into a clean, new 96-well plate, ready for downstream analysis.
At 4E's, we ensure quality by implementing rigorous testing and inspection protocols on our products, which allows us to deliver reliable laboratory equipment to our customers. Our knowledgeable and responsive support team provides excellent customer assistance, ensuring that our customers receive the best possible experience when working with us.
Customers
Answered calls
Emails answered
| Model | MultiEX 024L |
| Throughput | 1-24 Samples |
| Processing Volume | 50µl – 8 ml |
| Processing Time | 20 – 40min/run (depending on reagent and volumes) |
| Capacity | Supports up to 24 Reagent Strips or 6 Plates |
| Consumables | Reagent Strips (Single Sample) / Strip Plates (4 Samples) and Magnetic Rod Sleeves |
| Reagent Type | Magnetic bead-based reagent kits (open system) |
| Heating Temperature Range | 37°C to 125℃ |
| Temperature Accuracy | 1.5℃ |
| Mixing Method | Rotational Mixing (Rod Sleeves) + Linear Shaking (Plate) |
| Mixing Speed (Rod Sleeves) | 0-3000rpm |
| Magnetic Beads Recovery Rate | 98% |
| Inter-well Purification Variance | CV＜3% |
| Contamination Control | UV light sterilization，Filtration system |
| Program Management | Create&Edit and Delete options available |
| Data Storage Capacity | ＞500 programs |
| Display | 10-inch color touch screen |
| Extension Ports | 2 USB ports |
| Power Supply | 100-240V AC，50/60Hz |
| Noise | ＜60 dB |
| Weight | 32 kg |
| Dimension (W*D*H) | 349mm*440mm*388mm |
Processes large initial sample volumes (up to 8mL) for automated nucleic acid extraction with final elution volumes as low as 50 µL
The use of magnetic beads allows for efficient and selective capture of nucleic acid, resulting in high yields of pure DNA or RNA.
The touchscreen interface is easy to navigate and allows for quick and simple programming of extraction parameters.
Processes large initial sample volumes (up to 8mL) for automated nucleic acid extraction with final elution volumes as low as 50 µL
The use of magnetic beads allows for efficient and selective capture of nucleic acid, resulting in high yields of pure DNA or RNA.
The touchscreen interface is easy to navigate and allows for quick and simple programming of extraction parameters.
Powerful oscillation mixing technology that combines vortex mixing up to 3000 RPM within each well, and linear back-and-forth mixing of the entire plate for thorough mixing.
Built-in UV disinfection lamp eliminates cross-contamination and automatically powers off after disinfection. Built-in filtration system provides contamination-free ventilation
Multi-functional operating system with streamlined functions to edit program parameters for custom protocols, upgrade the system via USB, and import/export programs via USB
